Gravity: Dual Bipolar Stepper Motor Shield for Arduino (DRV8825)
Do you want to create projects with stepper motors such as a drafting instrument, a 3D printer, an auto curtain? As we all know, regular stepper motors are hard to drive, but with this stepper motor shield, you can easily drive 2 stepper motors via just 6 digital I/O pins.
This board is compatible with the Arduino UNO R3. This shield directly supports Xbee and Xbee form factor Wi-Fi, Bluetooth and RF modules and is easy to connect cables via screwless PC terminals. Each stepper motor has a code switch for adjusting driving modes to obtain different rotational speeds. Interfaces of the board include extension 6 channel Analog I/O, 8 channel Digital I/O & I2C.
Specifications
- Input Voltage: 8.2-45 VDC
- Output current: 1.6 A (Limited)
- Working voltage: 3.3/5 V
- Driving pin: D4, D5, D6, D7, D8, D12
- Microstep resolutions: full, 1/2, 1/4, 1, 8, 1/16, 1/32
- Support Dual Bipolar Stepper Motor
- Support XBee interface
- Compatible with the Arduino UNO R3, Leonardo, Mega microcontroller
- Dimension: 83 x 55 x 25 mm
- Weight: 48g
Resources
Package Contents
- 1x SDual Bipolar Stepper Motor Shield
Original: $31.60
-65%$31.60
$11.06More Images
